Simplified and Cost-Effective Design

• Returns braking energy to the grid through fully regenerative capability.
• Achieves near-unity power factor minimizing efficiency losses from excess reactive power and reducing utility costs and penalties.
• Maintains THDi at or below 5% through the 100th harmonic to support overall system compliance with IEEE 519 standards.

Enhanced Motor Performance and Longevity

• Provides true sine wave 3-phase output and eliminates voltage spikes.
• Minimizes common-mode currents to prevent bearing damage.
• Operates motors 9–12% cooler in testing, helping to extend motor service life.
• Eliminates the need for motor protection accessories, such as shaft grounding rings and insulated bearings.

Superior Power Quality and Efficiency

• Eliminates the need for external filters, AC reactors, harmonic filters, dv/dt filters, and ASD cables.
• Built-in filters reduce system footprint, lower installation costs, and minimize potential points of failure.

Intuitive Control and Monitoring

• Remote set up, monitoring, and control functionality via the WC1 app.
• Streamlined installation and commissioning.
