G9000 Series 100-2000kVA
- G9000 UPS T90N3P50KPAXSN+MBS Single Input Oneline
- G9000 UPS T90N3P50KPAXSN+MBS Dual Input Oneline
- G9000 UPS T90N3P50KPAXSN Oneline
- G9000 UPS T901H1D5MWWW-C+MBS Dual Input Oneline
- G9000 UPS T901H1D5MWWW-C+MBS Single Input Oneline
- G9000 UPS T901H2D0MWWW-C+MBS Single Input Oneline
- G9000 UPS T901H1D6MWWW-C+MBS Single Input Oneline
- G9000 UPS T901H1D3MWWW-C+MBS Single Input Oneline
- G9000 UPS T90S3S01MS6XSN+MBS Single Input Oneline
- G9000 UPS T901H2D0MWWW-C+MBS Dual Input Oneline
- G9000 UPS T901H2D0MWWW-C Oneline
- G9000 UPS T901H1D6MWWW-C+MBS Dual Input Oneline
- G9000 UPS T901H1D6MWWW-C Oneline
- G9000 UPS T901H1D5MWWW-C Oneline
- G9000 UPS T901H1D3MWWW-C+MBS Dual Input Oneline
- G9000 UPS T901H1D3MWWW-C Oneline
- G9000 UPS T90S3S01MS6XSN+MBS Dual Input Oneline
- G9000 UPS T90S3S01MS6XSN Oneline
- G9000 UPS T90S3S75KS6XSN+MBS Single Input Oneline
- G9000 UPS T90S3S75KS6XSN+MBS Dual Input Oneline
- G9000 UPS T90S3S75KS6XSN Oneline
- G9000 UPS T90S3S50KS6XSN+MBS Dual Input Oneline
- G9000 UPS T90S3S50KS6XSN+MBS Single Input Oneline
- G9000 UPS T90S3S50KS6XSN Oneline
- G9000 UPS T90S3S30KS6XSN+MBS Dual Input Oneline
- G9000 UPS T90S3S30KS6XSN+MBS Single Input Oneline
- G9000 UPS T90S3S30KS6XSN Oneline
- G9000 UPS T90S3S22KS6XSN2 Oneline
- G9000 UPS T90S3S22KS6XSN2+MBS Single Input Oneline
- G9000 UPS T90S3S22KS6XSN2+MBS Dual Input Oneline
- G9000 UPS T90S3S16KS6XSN Oneline
- G9000 UPS T90S3S16KS6XSN+MBS Single Input Oneline
- G9000 UPS T90S3S16KS6XSN+MBS Dual Input Oneline
- G9000 UPS T90S3S10KS6XSN2+MBS Dual Input Oneline
- G9000 UPS T90S3S10KS6XSN2+MBS Single Input Oneline
- G9000 UPS T90S3S10KS6XSN2 Oneline
- G9000 UPS T90S3S08KS6XSN+MBS Dual Input Oneline
- G9000 UPS T90S3S08KS6XSN+MBS Single Input Oneline
- G9000 UPS T90S3S08KS6XSN Oneline
- G9000 UPS T90S3S10KS6XSN2 Outline
- G9000 UPS T90S3S16KS6XSN2 Outline
- G9000 UPS T90S3S22KS6XSN2 Outline
- G9000 UPS T90S3S30KS6XSN Outline
- G9000 UPS T90S3S50KS6XSN Outline
- G9000 UPS T90S3S75KS6XSN Outline
- G9000 UPS T90S3S01MS6XSN Outline
- G9000 UPS T901H1D0MWWW-C Outline
- G9000 UPS T901H1D3MWWW-C Outline
- G9000 UPS T901H1D5MWWW-C Outline
- G9000 UPS T901H1D6MWWW-C Outline
- G9000 UPS T901H2D0MWWW-C Outline
- Cutsheet - G9000 100kVA r1-2
- Cutsheet - G9000 160kVA r1-2
- Cutsheet - G9000 225kVA r1-2
- Cutsheet - G9000 300kVA r1-2
- Cutsheet - G9000 500kVA r1-2
- Cutsheet - G9000 750kVA r1-2
- Cutsheet - G9000 1000kVA r1
- Guide Spec - G9000 Series 100-225kVA - r4
- Guide Spec - G9000 Enhanced Series 100-225kVA - r0
- Guide Spec - G9000 Series 300-750kVA - r5
- Guide Spec - G9000 Series 1000kVA - r1-1
- Spec Sheet - G9000 Enhanced 100kVA - r0
- Spec Sheet - G9000 Enhanced 160kVA - r0
- Spec Sheet - G9000 Enhanced 225kVA - r0
- G9000 Series 100kVA T90S3S10KS6XSN2 UPS Efficiency Curve
- G9000 Series 160kVA T90S3S16KS6XSN2 UPS Efficiency Curve
- G9000 Series 225kVA T90S3S22KS6XSN2 UPS Efficiency Curve
- G9000 Series 300kVA T90S3S30KS6XSN UPS Efficiency Curve
- G9000 Series 500kVA (400V) T90N3P50KPAXSN UPS Efficiency Curve
- G9000 Series 500kVA T90S3S50KS6XSN UPS Efficiency Curve
- G9000 Series 750kVA T90S3S75KS6XSN UPS Efficiency Curve
- G9000 Series 1000kVA T901H1D0MWWW-C UPS Efficiency Curve
- G9000 Series 1330kVA T901H1D3MWWW-C UPS Efficiency Curve
- G9000 Series 1500kVA T901H1D5MWWW-C UPS Efficiency Curve
- G9000 Series 2000kVA T901H2D0MWWW-C UPS Efficiency Curve
The G9000 Series UPS is available in capacities of 100, 160, 225, 300, 500, 750, 1000, 1330, 1500, 1600, and 2000kVA and comes with an industry-leading three-year onsite warranty. It is designed for stand-alone or parallel use in up to four-unit configurations (100-225kVA), eight-unit configurations (300-750kVA) or six-unit configurations (1000-2000kVA) without requiring the use of a special switchgear cabinet.
Using the new Toshiba IGBT technology in the rectifier/converter, DC/DC chopper, and the inverter sections of the UPS, the G9000's double-conversion topology provides an AC/DC/AC efficiencies of up to 97% at loads from 50% to 100%. Even at 20% loading, the efficiency remains greater than 94%. This is 10% to 20% better than current industry systems, making the G9000 excellent for N+1 parallel systems where loads are typically 30-40%.
Model |
Power (KVA) |
Input Voltage |
Input Phase |
Input Freq. |
Output Voltage |
Output Phase |
Output Frequency |
|---|---|---|---|---|---|---|---|
| T90S3S10KS6XSN2 | 100.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T90S3S16KS6XSN2 | 160.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T90S3S22KS6XSN2 | 225.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T90N3P50KPAXSN | 500.0KVA | 400V | 3PH | 50HZ/60HZ | 400V | 3PH | 50/60HZ |
| T90S3S50KS6XSF | 500.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T90S3S50KS6XSN | 500.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T90S3S65KS6XSN | 650.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T90S3S75KS6XSN | 750.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T901H1D0MWWW-C | 1000.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T901H1D3MWWW-C | 1330.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T901H1D5MWWW-C | 1500.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T90S3S30KS6XSN | 300.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T901H1D6MWWW-C | 1660.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
| T901H2D0MWWW-C | 2000.0KVA | 480V | 3PH | 60HZ | 480V | 3PH | 60HZ |
